AGT-R1V3-US
Smart. Scalable. Resilient.
The FranklinWH aGate X is a next-generation home energy management system designed to intelligently control and optimize your power sources—including solar, grid, batteries, and generators. Whether you’re aiming for backup power during outages or maximizing solar energy use, the aGate X brings advanced functionality and flexibility to your energy system.
Universal Compatibility
Works seamlessly with both microinverters and string inverters, enabling smooth integration with your current solar system.
Built-In Power Management
Eliminates the need for costly main panel upgrades with a 280A built-in busbar, certified for Power Conditioning System (PCS) functions.
✔ Reliable Backup Power
Equipped with smart circuit management, black start capability, and generator module integration to ensure your critical appliances stay powered—even after extended outages.
Intelligent Energy Optimization
The built-in Energy Management System (EMS) supports:
Self-consumption
Time-of-use optimization
Emergency backup mode
Seamless transitions between power sources
Residential Homes: Manage essential and backup loads efficiently
Backup Power Systems: Maintain power during outages
Energy Efficiency: Optimize energy usage and solar production
Mounting: Surface-mounted (indoor or outdoor)
Conduit Entry: Flexible access from bottom, left, or right
Enclosure: Weather-resistant NEMA 3R rated for durability
| Specification | Details |
|---|---|
| Model | AGT-R1V2-US |
| Nominal AC Voltage | 120/208V, 120/240V, 60 Hz |
| Phases | 2W + N + PE |
| Max Overcurrent Protection | 100A (Battery), 80A (Solar Input) |
| Backup Load Protection | Up to 200A |
| Internal Busbar Rating | 280A |
| Smart Circuit Management | Optional configurations available |
| Connectivity | Ethernet, Wi-Fi, Bluetooth, 4G |
| User Interface | FranklinWH App |
| Certifications | UL 1741, UL 916, CSA C22.2 |
| Dimensions (H x W x D) | 32" x 22" x 7" |
| Weight | 40 lbs |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Warranty | 12-Year Limited Warranty |
At Vortex Solar Supply, we go beyond just products—we provide solutions you can trust.
Trusted Quality: Only genuine, brand-new products from top-tier manufacturers
Expert Support: From product selection to installation, we’re here every step of the way
Secure Checkout: Safe, encrypted transactions for peace of mind
Real Customer Service: Email us at sales@vortexsolarsupply.com for expert help and personalized guidance
Power your home with confidence using the FranklinWH aGate X—a smart, scalable energy management hub that future-proofs your solar investment.
